Mill/Drill Machine, 1-1/2 Motor HP, 16" Swing, 150 to 3000 RPM

  • Item# 2LKP9
  • Mfr. Model# 2LKP9
  • Catalog Page# 903
  • UNSPSC# 27112703
Mill/Drill Machine, 1-1/2 Motor HP, 16" Swing, 150 to 3000 RPM close
close x

Using 360° Viewing:

  1. Rotate: Use top-to-bottom, side-to-side by use of mouse arrow.
  2. Zoom In: Double click on image.
  3. Zoom Out/Reset: Put photo at full zoom & then double click.
Megaphone How can we improve our Product Images?

Price $3,281.00 / each

Activate Now

to save with

Select AdvantageSM
This item requires
special shipping, additional charges may apply.
+ Add to List

Please sign in or register to access lists

Please sign in or register to access Quote

Jump to:
0 Stars
  • Shipping Weight 667.0 lbs.
Country of Origin China Country of Origin is subject to change.
Note: Product availability is real-time updated and adjusted continuously. The product will be reserved for you when you complete your order. More

Product Details

Versatile machines provide accurate milling, drilling, and boring capabilities. Enclosed R8 spindle has adjustable depth stop with scale.

View More

Technical Specs

  • Milling and Drilling Machine Product Grouping Mill/Drill Machines
  • Item Mill/Drill Machine
  • Swing 16"
  • Drilling Capacity Steel 1-1/2"
  • End Milling Capacity 3/4"
  • Face Milling Capacity 3"
  • Motor HP 1-1/2
  • Voltage 120/240
  • Table Work Surface 9-1/2 x 32"
  • Includes 1/2" Chuck, 2 1/2" Face Mill Cutter W/Arbors, R8/MT3 Arbor Adaptor, Work Light, 6 Piece R8 Collet Set 1/8 To 3/4 X 8ths, Way Covers
  • Corded/Cordless Corded
  • Longitudinal Travel 23"
  • Cross Travel 7"
  • Amps 23.0/11.5
  • Phase 1
  • Hz 60
  • RPM 150 to 3000
  • Chuck Size Not Included
  • Spindle R8
  • Spindle Taper R8
  • Spindle Speed 150 to 3000 rpm
  • Spindle Travel 5"
  • Spindle to Table 17"
  • Column Dia. 4-1/2"
  • Quill Dia. 3"
  • T-Slots 5/8"
  • Operation Manual
  • Features Fine Feed Handwheel With .001 Graduations With Quill Lock, Cast Iron Construction, Taper Roller Spindle Bearings, Depth Gauge, Precision Ground Work Table,Zero Setting Handwheel Dials With .001 Graduations
