Pneumatics
>
Air Compressors and Vacuum Pumps
>
Piston Air Compressor/Vacuum Pump

230 V

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Compressor Pump, TA Series, 1/3 HP, Voltage 115/230, 60 Hz, 1 Phase, 8.0/4.0 Full Load Amps, FNPT Inlet 1/4 In., FNPT Outlet 1/4 In., Max. PSI Cont./Int. 175, Free Air CFM @ 0 PSI 1.4, @ 50 PSI 1.27, @ 100 PSI 1.15, Length 14.5 In., Width 11.2 In., Height 7 In., Cast Iron Cylinder Material, 2 Cylinders, Motor Type Capcitor Start, Sound Rating 80 dbA, Articulating Piston Design, Agency Compliance UL (MOTOR ONLY), Temp. Range 32 to 104 F

Grainger Item #	3HCA5
Price (ea.)	$2,054.00
Brand	THOMAS INDUSTRIES
Mfr. Model #	270072
UNSPSC #	40151601
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	44.25
Availability	Typically in Stock
Catalog Page No.	4014
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $299.00 each.
Price shown may not reflect your price. Sign in or register.

Air Compressor, 1/3 HP, 1.4 CFM, 115/230 V

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Piston Air Compressor
Type		TA Series
HP		1/3
Voltage		115/230
Hz		60
Phase		1
Full Load Amps		8.0/4.0
(F)NPT Inlet (In.)		1/4
(F)NPT Outlet (In.)		1/4
Max. PSI Cont./Int.		175
Free Air CFM @ 0 PSI		1.4
Free Air CFM @ 50 PSI		1.27
Free Air CFM @ 100 PSI		1.15
Length (In.)		14.5
Width (In.)		11.2
Height (In.)		7
Cylinder Material		Cast Iron
Cylinders		2
Motor Type		Capacitor Start
RPM		1725
Sound Rating		80 dbA
Design		Articulating Piston
Finish		Gray Paint
Valve		Stainless Steel
Agency Compliance		UL (MOTOR ONLY)
Bearings		Permanently Lubricated
Compressor Material		Cast Iron and Aluminum
Temp. Range		32 to 104F
Thermal Protection		Yes
Power Cord		No
Application		Industrial Sweepers, Pond Aeration, Pneumatic Instrument Control
