Machining
>
Indexable Inserts
>
Turning Inserts

SUMITOMO Coated Carbide Insert, CNMG431EUP-AC830P

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Coated Carbide Insert, 0 Degrees , 80 Degrees Diamond, Style CNMG, Insert Size 0.500 In, Chip-Breaker EUP, Grade AC830P, Application General, Workpiece Material Steel and Stainless, Inscribed Circle 1/2 In, Insert Thickness 0.188 In, Nose Radius 0.016 In, Coating Super FF TiCN/Al2O3/TiN CVD, Cutting Direction Neutral, Mounting Hole Dia. 0.203, Mounting Style Clamp, Rake Positive, No. of Edges 4, ISO Number CNMG120404NUP-AC830P, ANSI Number CNMG431EUP-AC830P. Only shipped in quantities of 10.

Grainger Item #	4JZL4
Price (ea.)	$12.67
Brand	SUMITOMO
Mfr. Model #	CNMG431EUP-AC830P
UNSPSC #	23171618
Ship Qty.	10
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	0.02
Availability	Typically in Stock
Catalog Page No.	3626
Country of Origin (Country of Origin is subject to change.)	Japan

Qty.
Price shown may not reflect your price. Sign in or register.

Coated Carbide Insert, CNMG431EUP-AC830P

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Coated Carbide Insert
Relief Angle		0 Degrees
Insert Shape		80 Deg Diamond
Style		CNMG
Insert Size		0.500"
Chip-Breaker		EUP
Grade		AC830P
Application		General
Workpiece Material		Steel/Stainless Steel
Inscribed Circle		0.500"
Insert Thickness		0.1875"
Nose Radius		0.0157"
Coating		Super FF TiCN/Al2O3/TiN CVD
Cutting Direction		Neutral
Mounting Hole Dia.		0.203
Mounting Style		Clamp
Rake		Positive
No. of Edges		4
ISO Number		CNMG120404NUP-AC830P
ANSI Number		CNMG431EUP-AC830P
For Use With		DCLN, MCLN, Toolholders, A-MCLN Boring Bars
