Electrical
>
Distribution
>
Circuit Breakers

SQUARE D Circuit Breaker, 60 A

| Write a Review
| Read all Reviews
| Read all Ask & Answer

FA Circuit Breaker, Current Rating 60 Amps, Voltage Rating 240 Volts, Number of Poles 3, Phase Connection ABC, I Line Panelboard

Grainger Item #	1H040
Price (ea.)	$624.00
Brand	SQUARE D
Mfr. Model #	FA32060
UNSPSC #	39121602
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	5.75
Availability	Typically in Stock
Catalog Page No.	N/A
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $129.00 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Circuit Breaker
Type		Panelboard Mount
Circuit Breaker Type		Standard
Number of Poles		3
Amps		60
Voltage		240VAC
Max. DC Voltage (V)		250
AIR Rating		10k
AIR @ 120VAC		10k
AIR @ 125VDC		5k
AIR @ 240VAC		10k
AIR @ 48VDC		5k
AIR @ 65VDC		5k
Phase		3
Phase Connection		ABC
Terminal Connection		Lug
Min. Wire Size (AWG)		14
Max. Wire Size (AWG)		1/0
Length (In.)		9.00
Width (In.)		4.50
Depth (In.)		6.00
Instantaneous Trip		Fixed
High Amp Trip Setting		1450
Frame Size		100A/FA
For Use With		I Line Panelboards
Standards		UL, CSA, CE
Panelboard Mounting		Plug-In
