SQUARE D Circuit Breaker, 30 A

| Write a Review
| Read all Reviews
| Read all Ask & Answer

EDB Bolt On Circuit Breaker, Current Rating 30 Amperes, AC Voltage 480/277 Volts, Number of Poles 2, Minimum Wire Size 14 American Wire Gauge, Maximum Wire Size 6 American Wire Gauge, AIR Rating 18K, Used on NF Panelboard

Grainger Item #	3TW25
Price (ea.)	$529.00
Brand	SQUARE D
Mfr. Model #	EDB24030
UNSPSC #	39121601
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	2.2
Availability	Typically in Stock
Catalog Page No.	277
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $99.95 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Circuit Breaker
Type		Panelboard Mount
Circuit Breaker Type		Standard
Number of Poles		2
Amps		30
Voltage		480Y/277 VAC
AIR Rating		18k
AIR @ 120VAC		25k
AIR @ 240VAC		25k
AIR @ 277VAC		18k
AIR @ 480VAC		18k
Phase		1
Phase Connection		Any
Terminal Connection		Lug
Min. Wire Size (AWG)		14
Max. Wire Size (AWG)		6
Length (In.)		5.66
Width (In.)		1.96
Depth (In.)		4.05
Instantaneous Trip		Fixed
High Amp Trip Setting		875
Frame Size		125A/EDB
For Use With		NF Panelboards
Standards		UL, CSA
Panelboard Mounting		Bolt-On
