SQUARE D Circuit Breaker, I Line PB, 600A, 1 Phase

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Circuit Breaker, Panel Mount, Standard Circuit Breaker Type, Number of Poles 2, 600 Amps, 600VAC, AIR Rating 25kA, 100kA, 100kA, 65kA, 65kA, 1 Phase, Panelboard Mount Terminal Connection, Min. Wire Size (AWG) 3/0, Max. Wire Size (AWG) 500 kcmil, Length (In.) 12.80, Width (In.) 8.30, Depth (In.) 8.10, Adjustable Instantaneous Trip, High Amp Trip Setting 6000, Low Amp Trip Setting 1200, Frame Size M Frame, For Use With I Line Panelboards, Standards UL, CSA

Grainger Item #	6NHA3
Price (ea.)	$8,474.00
Brand	SQUARE D
Mfr. Model #	MJA266002
UNSPSC #	39121601
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	26.45
Availability	Typically in Stock
Catalog Page No.	279
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $999.00 each.
Price shown may not reflect your price. Sign in or register.

Circuit Breaker, I Line PB, 600A, 1 Phase

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Circuit Breaker
Type		Panel Mount
Circuit Breaker Type		Standard
Number of Poles		2
Amps		600
Voltage		600VAC
AIR Rating		25k
AIR @ 120VAC		100k
AIR @ 240VAC		100k
AIR @ 277VAC		65k
AIR @ 480VAC		65k
Phase		1
Phase Connection		AC
Terminal Connection		Panelboard Mount
Min. Wire Size (AWG)		3/0
Max. Wire Size (AWG)		500 kcmil
Length (In.)		12.80
Width (In.)		8.30
Depth (In.)		8.10
Instantaneous Trip		Adjustable
High Amp Trip Setting		6000
Low Amp Trip Setting		1200
Frame Size		M Frame
For Use With		I Line Panelboards
Standards		UL, CSA
