SQUARE D Circuit Breaker, Bolt On, EDB, 1Pole, 20A

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Circuit Breaker, Bolt On, EDB Type, Number of Poles 1, Voltage 480Y/277VAC, Amps 20, Single Phase, Any Phase Connection, Min Wire Size 14 AWG, Max Wire Size 6 AWG, Length 5.66 In, Width 0.98 In, Depth 4.05 In, Box Lug Terminal Connection, For Use With NF Panelboards, Frame Size 70 Amp/EDB, Standards UL/CSA

Grainger Item #	2JWC6
Price (ea.)	$946.50
Brand	SQUARE D
Mfr. Model #	EDB14020EPD
UNSPSC #	39121601
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	2.14
Availability	Typically in Stock
Catalog Page No.	277
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $129.00 each.
Price shown may not reflect your price. Sign in or register.

Circuit Breaker, Bolt On, EDB, 1Pole, 20A

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Circuit Breaker
Type		Panelboard Mount
Circuit Breaker Type		Ground Fault Equipment Protection (30mA)
Number of Poles		1
Amps		20
Voltage		277VAC
AIR Rating		18k
AIR @ 120VAC		18k
AIR @ 240VAC		18k
AIR @ 277VAC		18k
AIR @ 480VAC		18k
Phase		1
Phase Connection		Any
Terminal Connection		Lug
Min. Wire Size (AWG)		14
Max. Wire Size (AWG)		6
Length (In.)		5.66
Width (In.)		0.98
Depth (In.)		4.05
Instantaneous Trip		Fixed
High Amp Trip Setting		879
Frame Size		70A/EDB
For Use With		NF Panelboards
Standards		UL, CSA, CE
Panelboard Mounting		Bolt-On
