SQUARE D Circuit Breaker, Plug In, QD, 3Pole, 90A

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Circuit Breaker, Plug In, Standard Circuit Breaker Type, Number of Poles 3, Voltage 240VAC, Amps 90, Three Phase, ABC Phase Connection, Min Wire Size 4 AWG, Max Wire Size 300 AWG, Length 6.47 In, Width 4.50 In, Depth 3.02 In, Box Lug Terminal Connection, For Use With I-Line Panels, Frame Size 250 Amp/QD, Standards UL/CSA

Grainger Item #	2GPJ1
Price (ea.)	$1,918.00
Brand	SQUARE D
Mfr. Model #	QDA32090
UNSPSC #	39121601
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	6.73
Availability	Item ships within 6 business days from supplier
Catalog Page No.	279
Country of Origin (Country of Origin is subject to change.)	Not Available

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $199.00 each.
Price shown may not reflect your price. Sign in or register.

Circuit Breaker, Plug In, QD, 3Pole, 90A

Enlarge Image

Item		Circuit Breaker
Type		Panelboard Mount
Circuit Breaker Type		Standard
Number of Poles		3
Amps		90
Voltage		240VAC
AIR Rating		25k
AIR @ 120VAC		25k
AIR @ 240VAC		25k
Phase		3
Phase Connection		ABC
Terminal Connection		Lug
Min. Wire Size (AWG)		4
Max. Wire Size (AWG)		300 kcmil
Length (In.)		6.47
Width (In.)		4.50
Depth (In.)		3.02
Instantaneous Trip		Fixed
High Amp Trip Setting		1800
Frame Size		250A/QD
For Use With		I Line Panelboards
Standards		UL, CSA, CE
Panelboard Mounting		Plug-In
