SQUARE D Circuit Breaker, Plug In, HG, 2Pole, 50A

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Circuit Breaker, Plug In, Standard Circuit Breaker Type, Number of Poles 2, Voltage 600VAC, Amps 50, Single Phase, AB Phase Connection, Min Wire Size 14 AWG, Max Wire Size 3 AWG, Length 6.40 In, Width 4.10 In, Depth 4.36 In, Box Lug Terminal Connection, For Use With I-Line Panels, Frame Size 150 Amp/HG, Max. DC Voltage 250 V, Standards UL/CSA

Grainger Item #	2GNC6
Price (ea.)	$1,085.00
Brand	SQUARE D
Mfr. Model #	HGA260501
UNSPSC #	39121601
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	4.35
Availability	Item ships within 8 business days from supplier
Catalog Page No.	279
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $199.00 each.
Price shown may not reflect your price. Sign in or register.

Circuit Breaker, Plug In, HG, 2Pole, 50A

Enlarge Image

Item		Circuit Breaker
Type		Panelboard Mount
Circuit Breaker Type		Standard
Number of Poles		2
Amps		50
Voltage		600VAC
Max. DC Voltage (V)		250
AIR @ 120VAC		65k
AIR @ 125VDC		20k
AIR @ 240VAC		65k
AIR @ 480VAC		35k
AIR @ 600VAC		18k
AIR @ 48VDC		20k
AIR @ 65VDC		20k
Phase		1
Phase Connection		AB
Terminal Connection		Lug
Min. Wire Size (AWG)		14
Max. Wire Size (AWG)		3
Length (In.)		6.40
Width (In.)		4.10
Depth (In.)		4.36
Instantaneous Trip		Fixed
High Amp Trip Setting		850
Frame Size		150A/HG
For Use With		I Line Panelboards
Standards		UL, CSA, CE, NOM
Panelboard Mounting		Plug-In
