Pneumatics
>
Pneumatic System Components
>
Vacuum Ejectors

SMC Vacuum Ejector, Inline, Body, 1/4 In NPT

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Vacuum Ejector, Inline, Body Ported, Pressure Port Size 1/4 In. NPT, Vacuum Port Size 3/8 In. NPT, Exhaust Type 3/8 In. NPT, Supply Pressure Range 30 to 87 PSI, Vacuum Pressure Range 0 to -53 KPA, Vacuum Pressure @ 40 PSI -40 KPA, Vacuum Pressure @ 75 PSI -53 KPA, Vacuum Flow Rate 110Lpm, Orifice Dia. 1.5mm, Length 116.5mm, Width 22.45mm, Height 58.5mm, Weight 43g, Temp. Range 5 to 60 Degrees C, Includes Muffler

Grainger Item #	30J497
Price (ea.)	$60.60
Brand	SMC
Mfr. Model #	ZH15DL-T02-T03-T03
UNSPSC #	41103306
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	0.15
Availability	Typically in Stock
Catalog Page No.	3955
Country of Origin (Country of Origin is subject to change.)	Japan

Qty.
Price shown may not reflect your price. Sign in or register.

Vacuum Ejector, Inline, Body, 1/4 In NPT

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Vacuum Ejector,Inline,Body Ported
Pressure Port Size		1/4" NPT
Vacuum Port Size		3/8" NPT
Exhaust Type		3/8" NPT
Supply Pressure Range		30 to 87 PSI
Vacuum Pressure Range		0 to -53 KPA
Vacuum Pressure @ 40 PSI		-40 KPA
Vacuum Pressure @ 75 PSI		-53 KPA
Vacuum Flow Rate		110Lpm
Orifice Dia.		1.5mm
Length		116.5mm
Width		22.45mm
Height		58.5mm
Weight		43g
Temp. Range		5 to 60 Degrees C
Includes		Muffler
