SCHNEIDER ELECTRIC Relay, 2PDT, 30A, 24VAC Coil

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Relay, Power, Contact Form 2PDT, Pins 8, Base Type Square, Number of Contacts 4, Contact Amp Rating 30 R, Contact Amp Rating 30 L, Normally Closed Contact 3 Amp, Contact Material Silver Tin Oxide, Coil Volts 24VAC, Coil VA Rating 4, Hz 50/60, Height 1.65 In, Width 1.34 In, Standards UL, CE, CCN, RoHS

Grainger Item #	1DPP9
Price (ea.)	$38.50
Brand	SCHNEIDER ELECTRIC
Mfr. Model #	RPF2BB7
UNSPSC #	39121514
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	0.19
Availability	Typically in Stock
Catalog Page No.	352
Country of Origin (Country of Origin is subject to change.)	China

Qty.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Relay
Type		Power
Contact Form		DPDT
Pins		8
Base Type		Square
Number of Contacts		4
Contact Amp Rating (Resistive)		30 NO/3 NC
Contact Amp Rating (Inductive)		30 NO/3 NC
Contact Material		Silver Tin Oxide
Coil Volts		24VAC
Coil VA Rating		4
Hz		50/60
Height (In.)		1.65
Width (In.)		1.34
Standards		UL, CE, CCN, RoHS
