SCHNEIDER ELECTRIC AC Drive, Max Output 2.3A

| Write a Review
| Read all Reviews
| Read all Ask & Answer

AC Drive, Variable Frequency, Max. HP 1, Max. Output Amps 2.3, 400 to 480 Voltage, 400 to 480 Voltage Output, Input Phase AC Three Phase, Output Phase AC Three Phase, Starting Torque ( Percent) 110, Torque @ 1 Hz ( Percent) 110, Frequency Setting (Hertz) 50 or 60, Output Frequency (Hertz) 0.1 - 599, Acceleration Adjust (Sec.) 0.1 to 999.9, Deceleration Adjust (Sec.) 0.1 to 999.9, Dynamic Braking Yes, Open, IP20 Enclosure, Height (In.) 9.6, Width (In.) 9.7, Depth (In.) 12, 150

Grainger Item #	22A645
Price (ea.)	$934.50
Brand	SCHNEIDER ELECTRIC
Mfr. Model #	ATV61H075N4
UNSPSC #	26111503
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	9.65
Availability	Typically in Stock
Catalog Page No.	342
Country of Origin (Country of Origin is subject to change.)	Indonesia

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $129.00 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		AC Drive
Drive Type		Variable Frequency
Max. HP		1
Max. Output Amps		2.3
Voltage		400-480
Voltage Output		400-480
Input Phase AC		3
Output Phase AC		3
Starting Torque (%)		110
Torque @ 1 Hz (%)		110
Frequency Setting (Hertz)		50/60
Output Frequency (Hertz)		0.1 - 599
Acceleration Adjust (Sec.)		0.1 to 999.9
Deceleration Adjust (Sec.)		0.1 to 999.9
Dynamic Braking		Yes
Enclosure		Open, IP20
Height (In.)		9.6
Width (In.)		9.7
Depth (In.)		12
Functions		150
Control Type		Asynchronous Motors: Volts Per Hz (2 Or 5 Points), Sensorless Flux Vector Control, Energy Saving, V/F Quad. Synchronous Motors: Vector Control Without Speed Feedback.
Key Pad Lockout		Yes
Start/Stop Control		By Keypad or Logic Input
Programmed For		Logic Input
Protection		Overvoltage/Undervoltage, Motor Thermal Overload, Drive Thermal Overload, Phase to Phase or Phase to Ground Short Circuit, Input/Output Phase Loss,Overbraking
Control Method		By Keypad or Logic Input
Accepts Input Control Signal		Yes
Displays		LED and Door Mount LCD
Digital Readout		Hz, Amps, kW and Volts
For Use With		3-Phase Inverter Duty Motor
Agency Compliance		UL508C, CSA, CE, C-Tick, GOST,SEMI 47 compliant
Green Environmental Attribute		Product Contributes To Reducing Energy Consumption
Green Certification or Other Recognition		RoHS Compliant
