RED HEAD Wedge Anchor, Stl, 3/4x7 L, PK 10

Wedge Anchor, Fully Threaded, Carbon Steel, Thread Size 3/4-10, Overall Length 7 In, Thread Length 5 1/8 In, Min Embedment 3 1/4 In, Max Work Thickness 3 In, Ultimate Tension in 4000 PSI Concrete 10, 840 Lb, Ultimate Shear in 4000 PSI Concrete 13, 720 Lb, Meets/Exceeds US Government GSA Specifications FF-S-325 Group II, Type 4, Class I, Includes Nuts And Washers, Package 10
  • Grainger Item #3A465
    Price (pk.)$53.80
    Package Qty.10
    BrandRED HEAD
    Mfr. Model #WS-3470
    UNSPSC #31162102
    Ship Qty. 1
    Sell Qty. (Will-Call) 1
    Ship Weight (lbs.)9.6
    Availability Typically in Stock
    Catalog Page No.3348
    Country of Origin
    (Country of Origin is subject to change.)
    USA
  • See Compliance & Restrictions for important safety & regulatory information.
  • Price shown may not reflect your price. Sign in or register.
Check Availability Use your ZIP code to estimate availability.
  •
  •
  • Please wait...
ItemWedge Anchor
TypeFully Threaded
MaterialCarbon Steel
Anchor Dia.3/4"
Anchor Length7"
Thread Size3/4-10
Thread Length5-1/8"
Min. Embedment3-1/4"
Embedment In Concrete6-5/8"
Max. Work Thickness3"
Ultimate Pullout (Lb.)17700
Ultimate Shear (Lb.)23,740
Ultimate Shear in 4000 PSI Concrete (Lb.)13,720
Ultimate Tension in 4000 PSI Concrete (Lb.)10,840
Agency ComplianceUL
Meets/ExceedsA-A-1923A Type 4
IncludesNuts and Washers
Package Quantity10
