NATIONAL CONTROLS On Delay Relay, DPDT, 240VAC

| Write a Review
| Read all Reviews
| Read all Ask & Answer

On Delay Relay, Time Delay, Contact Form DPDT, Pins 8, Base Type Octal, Number of Contacts 4, Function On Delay, Contact Amp Rating 10 R, HP @ 120V 1/3, HP @ 240V 1/2, Coil Volts 240VAC, Hz 50/60, Min. Time Setting 0.05 Sec., Max. Time Setting 999 Min., Operating Functions 1, Standards UL/CUL

Grainger Item #	5DPZ6
Price (ea.)	$98.30
Brand	NATIONAL CONTROLS
Mfr. Model #	A1M-0999M-465
UNSPSC #	39121519
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	0.34
Availability	Typically in Stock
Catalog Page No.	358
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $16.95 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Time Delay Relay
Type		Plug-In
Contact Form		DPDT
Pins		8
Base Type		Octal
Socket		5X852, 1EGP3, 1EGP5
Number of Contacts		4
Function		On Delay
Contact Amp Rating (Resistive)		10
HP @ 120V		1/3
HP @ 240V		1/2
Coil Volts		230VAC
Hz		50/60
Min. Time Setting		0.05 sec.
Max. Time Setting		999 min.
Standards		UL/CUL
