MULTIFAN Exhaust Fan Kit, 28 In Dia, 8200 CFM, 240 V

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Corrosion Resistant Exhaust Fan Kit, 1 Phase, Corrosion Resistant, Unassembled, Blade Dia. 28 In., Propeller Dia. 28 In., Number of Blades 5, Motor RPM 1050, Full Load Amps 3.2, Assembled/Unassembled Unassembled, Voltage 240V, 60 Hz, CFM @ 0.000-In. SP 8200, CFM @ 0.050-In. SP 8075, CFM @ 0.125-In. SP 7825, dBA @ 7 Feet 60, Max. Ambient Temperature 140 Degrees F, Motor HP 0.68, Motor Type Permanent Split Capacitor, Motor Enclosure Totally Enclosed Air Over, Motor Insulation Class F

Grainger Item #	7HY19
Price (ea.)	$607.50
Brand	MULTIFAN
Mfr. Model #	7HY19
UNSPSC #	40101604
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	37.9
Availability	Typically in Stock
Catalog Page No.	4460
Country of Origin (Country of Origin is subject to change.)	Netherlands

Qty.
Price shown may not reflect your price. Sign in or register.

Exhaust Fan Kit, 28 In Dia, 8200 CFM, 240 V

Enlarge Image

Item		Corrosion Resistant Exhaust Fan Kit
Phase		1
Blade Dia.		28"
Number of Blades		5
Motor RPM		1050
Full Load Amps		3.2
Assembled/Unassembled		Unassembled
Voltage		240V
Hz		60
CFM @ 0.000-In. SP		8200
CFM @ 0.050-In. SP		8075
CFM @ 0.125-In. SP		7825
dBA @ 7 Feet		60
Max. Ambient Temperature		140 Degrees F
Motor HP		0.68
Motor Type		Permanent Split Capacitor
Motor Enclosure		Totally Enclosed Air Over
Motor Insulation		Class F
Bearing Type		Sealed Ball
Watts		725
Outside Dia.		5-3/8"
Depth		9-3/4"
Blade Material		Polypropylene
Mounting Position		Vertical or Horizontal
Speed Control		1DGZ5
Standards		UL Recognized Motor (E219656)
Includes		Propeller, Direct Drive Motor and 4 Motor Mounting Arms
