MARATHON ELECTRIC Vector Motor, 30.0 lb-ft, 10 HP, 230/460 V

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Vector Motor, 3-Phase, Totally Enclosed Nonventilated, 10 HP, Torque 30.0 lb.-ft., Nameplate RPM 1774, Speed Range 1000:1 CT, Max. Speed 3600 RPM, NEMA/IEC Frame 215TC, Max. Operating Frequency 120 Hz, Voltage 230/460, 60 Hz, 3 Phase, 27.0/13.5 Full Load Amps, Face/Base Mounting, Horizontal or Vertical Mounting Position, CW/CCW Rotation, Ball Bearings, 1.0 Service Factor, Thermal Protection T-Stats, Insulation Class F, Ambient Temperature 40 Degrees C, Nominal Efficiency 0.902

Grainger Item #	5THY9
Price (ea.)	$2,261.00
Brand	MARATHON ELECTRIC
Mfr. Model #	215THTL7726
UNSPSC #	26101612
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	182.0
Availability	Typically in Stock
Catalog Page No.	36
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $299.00 each.
Price shown may not reflect your price. Sign in or register.

Vector Motor, 30.0 lb-ft, 10 HP, 230/460 V

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Vector Motor
Motor Type		3-Phase
Enclosure		Totally Enclosed Nonventilated
HP		10
Torque		30.0 lb.-ft.
Nameplate RPM		1774
Speed Range		1000:1 CT
Max. Speed		3600 RPM
NEMA/IEC Frame		215TC
Frame		215TC
Max. Operating Frequency		120 Hz
Voltage		230/460
Hz		60
Phase		3
Full Load Amps		27.0/13.5
Mounting		Face/Base
Mounting Position		Horizontal or Vertical
Rotation		CW/CCW
Bearings		Ball
Service Factor		1.0
Thermal Protection		T-Stats
Insulation Class		F
Insulation Feature		Patented MAX GUARD
Ambient Temperature		40 Degrees C
Nominal Efficiency		0.902
Efficiency Group		EPAct
NEMA Design		A
Frame Material		Aluminum
Finish		Black
Base		Rigid
Duty		Inverter Duty, 1000:1 CT
Encoder Acceptable		Yes
Encoder Shaft		5/8 x 1-3/4"
Shaft Dia.		1-3/8"
Shaft Length		3-1/8"
Overall Length		23-1/16"
RPM Range		1400-1800
Standards		UL Recognized (E6312), CSA Certified (LR2025), CE
Warranty		3 yr.
