Material Handling
>
Hoist and Rigging
>
Air Chain Hoist

INGERSOLL-RAND Air Chain Hoist, 1100 lb. Cap., 10 ft. Lft

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Air Chain Hoist, Load Capacity 1100 lb., Series CL500K, Suspension Trolley, Control Pendant, Lift 10 ft., Lift Speed 0 to 16 fpm, Min. Between Hooks 18-5/8 In., Reeving 2, Housing Length 12-25/32 In., Housing Width 5-1/8 In., Overall Length 12-25/32 In., Overall Width 5-1/8 In., Trolley Type Manual Push, Brake Self Adjusting, Fits Beam Flange W 2-19/32 In. to 8 In., Minimum Radius Curve 36 In., Air Consumption 32 scfm, Air Pressure 90 psi, Yellow, Finish Powder Coated, Inlet Size 3/8 In. NPT

Grainger Item #	4WZV8
Price (ea.)	$4,344.00
Brand	INGERSOLL-RAND
Mfr. Model #	CL500K-2DA10-C6U
UNSPSC #	24101602
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	78.0
Availability	Item ships within 38 business days from supplier
Catalog Page No.	1422
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $529.00 each.
Price shown may not reflect your price. Sign in or register.

Air Chain Hoist, 1100 lb. Cap., 10 ft. Lft

Enlarge Image

Item		Air Chain Hoist
Load Capacity		1100 lb.
Series		CL500K
Suspension		Trolley
Control		Pendant
Lift		10 ft.
Lift Speed		0 to 16 fpm
Min. Between Hooks		18-5/8"
Reeving		2
Housing Length		12-25/32"
Housing Width		5-1/8"
Overall Length		12-25/32"
Overall Width		5-1/8"
Trolley Type		Manual Push
Brake		Self Adjusting
Fits Beam Flange W		2-19/32" to 8"
Minimum Radius Curve		36"
Air Consumption		32 scfm
Air Pressure		90 psi
Color		Yellow
Finish		Powder Coated
Inlet Size		3/8" NPT
Noise Level		75 dBa
Standards		ANSI B30.16
