HONEYWELL Premium Mini Snap Swch, 3A, SPDT, Pin Plngr

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Premium Miniature Snap Switch, V-Basic Series, Type of Actuator Pin PlungerContact Form SPDT, Current Rating 3A, Voltage Rating 277VAC, Terminal Type Quick Connect, Operating Force 8 oz., Max. Pretravel 0.047 In., Release Force 2.00 oz., Differential Travel 0.002 to 0.010 In., Over Travel 0.05 In., Length 1.14 In., Height 0.63 In., Depth 0.4 In., Mounting Dimension 0.41 x 0.87 In. Centers, Operating Temp. Range -40 Degrees to 180 Degrees F, Housing Material PCT Polyester Thermoplastic

Grainger Item #	24A315
Price (ea.)	$3.16
Brand	HONEYWELL
Mfr. Model #	V7-7B19E9
UNSPSC #	39121505
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	0.01
Availability	Typically in Stock
Catalog Page No.	417
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Price shown may not reflect your price. Sign in or register.

Premium Mini Snap Swch, 3A, SPDT, Pin Plngr

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Premium Miniature Snap Switch
Series		V-Basic
Type of Actuator		Pin Plunger
Contact Form		SPDT
Current Rating		3A
Voltage Rating		277VAC
Terminal Type		Quick Connect
Operating Force		8 oz.
Max. Pretravel		0.047"
Release Force		2.00 oz.
Differential Travel		0.002 to 0.010"
Over Travel		0.05"
Length		1.14"
Height		0.63"
Depth		0.4"
Mounting Dimension		0.41 x 0.87" Centers
Operating Temp. Range		-40 Degrees to 180 Degrees F
Housing Material		PCT Polyester Thermoplastic
Standards		UL, CSA, ENEC
