Material Handling
>
Hoist and Rigging
>
Electric Hoists

9 fpm

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Electric Chain Hoist, Capacity 500 lb., Lift 10 ft.Lift Speed 53/9 fpm, Motor HP 1.2, Voltage 230, 3 Phase, Min. Between Hooks 16-5/16 In., 5.1 Amps @ Low Volts, Classification H4, Housing Depth 7-1/2 In., Housing Length 22-1/4 In., Housing Width 13-11/16 In., Headroom 16-5/16 In., Reeving 1, Brake Electromagnetic, Clutch Friction Clutch, Control 110v, Control Cord 6 ft.Finish Electrostatic EnamelLubrication Oil Bath, Thermal Protection Yes, Beam Height 3-1/4 In., Flange Width 2-1/4 to 4 In.

Grainger Item #	25K607
Price (ea.)	$4,180.00
Brand	HARRINGTON
Mfr. Model #	NERP003HD-10 / 230v
UNSPSC #	24101602
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	91.0
Availability	Item ships within 8 business days from supplier
Catalog Page No.	1411
Country of Origin (Country of Origin is subject to change.)	Japan

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $529.00 each.
Price shown may not reflect your price. Sign in or register.

Item		Electric Chain Hoist
Capacity		500 lb.
Lift		10 ft.
Lift Speed		53/9 fpm
Motor HP		1.2
Voltage		230
Phase		3
Min. Between Hooks		16-5/16"
Amps @ Low Volts		5.1
Classification		H4
Housing Depth		7-1/2"
Housing Length		22-1/4"
Housing Width		13-11/16"
Headroom		16-5/16"
Reeving		1
Brake		Electromagnetic
Clutch		Friction Clutch
Control		110v
Control Cord		6 ft.
Finish		Electrostatic Enamel
Lubrication		Oil Bath
Thermal Protection		Yes
Beam Height		3-1/4"
Flange Width		2-1/4 to 4"
Minimum Radius Curve		43-5/16"
Standards		ANSI/ASME B30.16, ASME HST-1M, NFPA70 UL1340 RoHS
Includes		Chain Container, Quick Disconnect Plugs On Pendant And Power Cords, 10 Year Brake Warranty
