GUARDIAN ELECTRIC Solenoid, Box Frame, 24DC, 132mA, 182 Ohms

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Solenoid, Box Frame, Body Length 1 1/8 In., Length 1 1/8 In., Width 3/4 In., Depth 3/4 In., Coil Volts 24DC, Seated Amps 132mA, Seated Watts 3.6, Coil Resistance (Ohms) 182, Coil Insulation Class 105, Terminals Solder Lug, Duty Cycle Continuous, Material of Construction Steel, Mounting Holes 4-40 UNC-2B (2 HOLES), From Mounting Holes to Plunger Hole 17/32 In., Standards UL, RoHs

Grainger Item #	5EGN9
Price (ea.)	$14.86
Brand	GUARDIAN ELECTRIC
Mfr. Model #	22-C-24D
UNSPSC #	31251510
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	0.11
Availability	Typically in Stock
Catalog Page No.	397
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Price shown may not reflect your price. Sign in or register.

Solenoid, Box Frame, 24DC, 132mA, 182 Ohms

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Solenoid
Type		Box Frame
Stroke Range		1/8 to 3/8"
Pull Force Range		1 to 3 oz.
Width (In.)		3/4
Depth (In.)		3/4
Length (In.)		1-1/8
Body Length (In.)		1-1/8
Coil Volts		24DC
Seated Amps		132mA
Seated Watts		3.6
Coil Resistance (Ohms)		182
Coil Insulation		Class 105
Terminals		Solder Lug
Duty Cycle		Continuous
Material of Construction		Steel
Mounting Holes		4-40 UNC-2B (2 Holes)
From Mounting Holes to Plunger Hole (In.)		17/32
Standards		UL, RoHs
