FUJI ELECTRIC 460V, 3-Phase, 5HP, 9A, FRENIC-MEGA

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Adjustable Frequency Drive, Constant & Variable Torque, Max. HP 5, Max. Output Amps 9, 380-480 Voltage, Variable Voltage Output, Input Phase AC Single & Three, Output Phase AC Three, Starting Torque ( Percent) 200, Torque @ 1 Hz ( Percent) 200, Frequency Setting (Hertz) Keypad, 0 to 10 Vdc, 0 to 5 Vdc or 4 to 20 Ma Input, EtherNet Option Card, DeviceNet Option Card, CC-Link Card, PROFIBUS DP Card, CANopen Card, See Additional Option cards, Output Frequency (Hertz) 0 to 500

Grainger Item #	33M567
Price (ea.)	$1,270.00
Brand	FUJI ELECTRIC
Mfr. Model #	FRN005G1S-4U
UNSPSC #	26111503
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	10.2
Availability	Typically in Stock
Catalog Page No.	346
Country of Origin (Country of Origin is subject to change.)	Not Available

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $199.00 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Adjustable Frequency Drive
Drive Type		Constant & Variable Torque
Max. HP		5
Max. Output Amps		9
Voltage		380-480
Voltage Output		380-480
Input Phase AC		1 or 3
Output Phase AC		3
Starting Torque (%)		200
Torque @ 1 Hz (%)		200
Frequency Setting (Hertz)		Keypad, 0 to 10 Vdc, 0 to 5 Vdc or 4 to 20 Ma Input, EtherNet Option Card,DeviceNet Option Card, CC-Link Card, PROFIBUS DP Card, CANopen Card,See Additional Option cards
Output Frequency (Hertz)		0 to 500
Acceleration Adjust (Sec.)		0 to 6000 seconds, Linear/S curve, Curver Linear, 1 to 4 switchable
Deceleration Adjust (Sec.)		0 to 6000 seconds, Linear/S curve, Curver Linear, 1 to 4 switchable
Dynamic Braking		Built in Braking unit & resistor
Enclosure		IP20
Functions		Keypad programming, Loader computer program, Option Cards
Control Type		Analog 0 to 10 Vdc, 5 Vdc, 4 to 20 Ma & Digital
Key Pad Lockout		Key pad Programming Lockout
Start/Stop Control		Yes Keypad & Terminal
Protection		Electronic Thermal Overload 1 through 4 motor, Over Current, Over Voltage, Low Voltage, PG, PID, Heatsink Overheat, Input & outpuy phase loss, Communication Error.
Control Method		V/f, Dynamic torque vector, V/f control w/ speed sensor or dynamic torque control w/ spped sensor, Vector control w/ out speed sensor, Vector control w/ speed sensor & optional PG card mounted.
Accepts Input Control Signal		Digital & Analog
Displays		LCD Monitor & Green Run Indicator
Digital Readout		7 Segment LED Monitor
For Use With		General Purpose & IInverter Duty 3 phase motors
Agency Compliance		C UL & US Listed, CE & RoHS Directives
