HVAC and Refrigeration
>
Cooling Fans and Accessories
>
Axial Fans

3In W

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Flatpack Axial Fan, Shape Square, Fan Dia. 1-1/2 In., CFM @ 0.000-In. SP 32.4, Voltage 24VDC, 0.25 Amps, 5.5 Watts, Electrical Connections 13-2/5 In. Leads AWG 22, 55 dBA, Bearings BallFan RPM 2200, Height 5-1/3 In., Width 5-1/3 In., Depth 1-1/2 In., Mounting Flange, Mounting Position Vertical or Horizontal, Mounting Eye O.C. 4-7/8 In., Motor Type Brushless DC, Motor Insulation Class E, Thermal Protection Electronic, Max. Ambient Temp. 167�F, Blade Material Fiberglass Reinforced Plastic

Grainger Item #	5AGE7
Price (ea.)	$91.70
Brand	EBM
Mfr. Model #	RG90-18/14N
UNSPSC #	40101604
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	1.32
Availability	Typically in Stock
Catalog Page No.	4473
Country of Origin (Country of Origin is subject to change.)	Germany

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $16.95 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Flatpack Axial Fan
Shape		Square
Fan Dia.		1-1/2"
CFM @ 0.000-In. SP		32.4
Voltage		24VDC
Amps		0.25
Watts		5.5
Electrical Connections		13-2/5" Leads AWG 22
dBA		55
Bearings		Ball
Fan RPM		2200
Height		5-1/3"
Width		5-1/3"
Depth		1-1/2"
Mounting		Flange
Mounting Position		Vertical or Horizontal
Mounting Eye O.C.		4-7/8"
Motor Type		Brushless DC
Motor Insulation		Class E
Thermal Protection		Electronic
Max. Ambient Temp.		167�F
Blade Material		Fiberglass Reinforced Plastic
Housing Material		Fiberglass Reinforced Plastic with Galvanized Steel Base
Housing Finish		Black Painted
Standards		UL, VDE, CSA Component Recognized
