DAYTON Pump, Turbine, 7 1/2 HP

Turbine Pump, Bronze-Fitted, 7 1/2 HP, 3 Phase, Voltage 208-230/460, Inlet 1 1/4 In., Outlet 1 In., Max. Pressure 300 PSI, Length 17 1/32 In., Height 8 1/2 In., Width 8 3/8 In.
  • Grainger Item #4UP66
    Price (ea.)$3,022.00
    BrandDAYTON
    Mfr. Model #4UP66
    UNSPSC #40151526
    Ship Qty. 1
    Sell Qty. (Will-Call) 1
    Ship Weight (lbs.)135.0
    Availability Item ships within 6 business days from supplier
    Catalog Page No.4087
    Country of Origin
    (Country of Origin is subject to change.)
    USA
  • Price shown may not reflect your price. Sign in or register.
ItemTurbine Pump
TypeBronze-Fitted
HP7-1/2
Phase3
Voltage208-230/460
Inlet (In.)1-1/4
Outlet (In.)1
Motor EnclosureTEFC
NEMA/IEC Frame56C
Motor Type3-Phase, TEFC
Wetted MaterialsCast Iron, Bronze Fitted
Impeller MaterialBronze
Housing MaterialCast Iron
Volute MaterialCast-Iron, Bronze Fitted
Screw MaterialSteel
Seal TypeType 21
Seal MaterialCarbon, Ceramic, Buna
Seal ApplicationLow Flow, High Head
Max. Liquid Temp. (F)-20 to 230
GPM @ 10 PSI41.0
GPM @ 20 PSI40.6
GPM @ 30 PSI40.0
GPM @ 50 PSI38.0
GPM @ 60 PSI37.8
GPM @ 75 PSI36.0
GPM @ 100 PSI34.5
GPM @ 150 PSI29.5
Max. Pressure (PSI)300
Best Efficiency GPM @ Head (Ft.)30 GPM @ 155 PSI
Best Efficiency Range GPM @ Head (Ft.)25.0-37.5 GPM @ 135-63 PSI
Max. Specific Gravity1.00 SP
Max. Case Pressure (PSI)300
Max. Fluid Viscosity250 SSU
Inlet Pressure (PSI)200
Impeller TypeRegenerative Turbine
Bearing TypeSealed Ball Bearing (Motor Bearing)
DutyContinuous
Max. Dia. Solids (In.)25 Microns
Port Rotation90 Increments
Drain Plug180 From Inlet Port
Agency ComplianceCE ON MOTOR ONLY
ApplicationFor Boiler Feed and Condensate Return Service, Low Flow, Pumping Clean Fluids, Nonflammable Liquids Compatible with Pump Component Materials
Length (In.)17-1/32
Height (In.)8-1/2
Width (In.)8-3/8
ConstructionBronze Impeller, Buna N O-Ring Gaskets, Mechanical Seal with Buna N and Stainless Steel Parts and Carbon/Ceramic Seats
IncludesCast Casing with Bronze Impeller
