DAYTON Relay, SPDT, 5 Pins, 120VAC

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Power Relay, Coil Voltage 120 VAC, Contact Current Rating Inductive 30 Amps, Contact Current Rating Resistive @ 28 VDC 30 Amps, Contact Current Rating Resistive @ 300 VAC 40 Amps, Coil Current Rating 10VA, Power Rating @ 240 VAC 1.5 HP, Power Rating @ 480 VAC 1.5 HP, Contact Form SPDT, Contact Point 5, Length 2.50 Inches, Height 2.30 Inches, Width 2.50 Inches

Grainger Item #	5Z542
Price (ea.)	$33.45
Brand	DAYTON
Mfr. Model #	5Z542
UNSPSC #	39121514
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	0.25
Availability	Typically in Stock
Catalog Page No.	352
Country of Origin (Country of Origin is subject to change.)	China

Qty.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Relay
Type		Power, Open Style
Contact Form		SPDT
Pins		5
Contact Amp Rating (Resistive)		40
Contact Amp Rating (Inductive)		30
Contact Material		Silver Cadmium Oxide
HP @ 120V		1-1/2
Coil Volts		120VAC
Height (In.)		2.30
Width (In.)		2.50
Depth (In.)		2.50
Standards		E40944
