Motors
>
HVAC Motors
>
4.4 Inch Diameter Motors

DAYTON HVAC Motor, 1/11 HP, 1000 rpm, 120V

| Write a Review
| Read all Reviews
| Read all Ask & Answer

HVAC Motor, Shaded Pole, Open Air-Over, 1/11 HP, Nameplate RPM 1000, Number of Speeds 1, NEMA/IEC Frame Nonstandard, Voltage 115, 60 Hz, 1 Phase, Full Load Amps 3.1, Stud Mounting, Thermal Protection One Shot, Insulation Class B, Service Factor 1.0, Sleeve Bearings, Max. Ambient Temp. 40 Degrees C, Rotation CWSE, Length Less Shaft 2-7/16 In., Shaft Dia. 1/2 In., Shaft Length 2-3/4 In., Body Dia. 5 In., Stud/Base Mtg. Pattern 4-1/16 x 4-1/16 x 4-1/16 In.Duty Continuous

Grainger Item #	10J151
Price (ea.)	$56.15
Brand	DAYTON
Mfr. Model #	10J151
UNSPSC #	26101602
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	4.46
Availability	Typically in Stock
Catalog Page No.	62
Country of Origin (Country of Origin is subject to change.)	China

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $12.95 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		HVAC Motor
Motor Type		Shaded Pole
Enclosure		Open Air-Over
HP		1/11
Nameplate RPM		1000
Number of Speeds		1
NEMA/IEC Frame		Nonstandard
Frame		Nonstandard
Voltage		115
Hz		60
Phase		1
Full Load Amps		3.1
Mounting		Stud
Thermal Protection		One Shot
Insulation Class		B
Service Factor		1.0
Bearings		Sleeve
Max. Ambient Temp.		40 Degrees C
Rotation		CWSE
Length Less Shaft		2-7/16"
Shaft Dia.		1/2"
Shaft Length		2-3/4"
Body Dia.		5"
Stud/Base Mtg. Pattern		4-1/16 x 4-1/16 x 4-1/16"
Duty		Continuous
RPM Range		1000-1380
Standards		UL Recognized 507, CSA Certified
