Pumps
>
Drum and Barrel Pumps
>
Drum Pumps

DAYTON Drum Pump, 3/4 HP, Air, 55 gal. Drums, 48 In

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Electric Operated Drum Pump, Motor and Tube, 3/4 HP, 7500 RPM, Air Motor, 316 SS Pump Body Material, 316 SS, PTFE Wetted Materials, PTFE Gasket Material, Maximum Head 50 ft, Max. Pressure 21 psi, Max. Temp. 175 Degrees F, Max. Viscosity 750 CPS, Inlet Size 1.6 In, Outlet Size 1 In Barb, Overall Length 48 In, For Use On 55 Gallon Drums

Grainger Item #	16A167
Price (ea.)	$2,461.00
Brand	DAYTON
Mfr. Model #	16A167
UNSPSC #	40151529
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	20.0
Availability	Typically in Stock
Catalog Page No.	4098
Country of Origin (Country of Origin is subject to change.)	Not Available

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $299.00 each.
Price shown may not reflect your price. Sign in or register.

Drum Pump, 3/4 HP, Air, 55 gal. Drums, 48 In

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Electric Operated Drum Pump
Type		Motor and Tube
HP		3/4
RPM		7500
Motor Enclosure		Air
Motor Type		Air
Pump Body Material		316 SS
Wetted Materials		316 SS, PTFE
Gasket Material		PTFE
For Use On		55 Gallon Drums
GPM		12
Maximum Head		50 ft
Max. Pressure		21 psi
Max. Temp.		175 Degrees F
Max. Viscosity		750 CPS
Max. GPM for Oil		3
Max. GPM for Water		13
Inlet Size		1.6"
Outlet Size		1" Barb
Discharge Tube Outlet ID Size		1"
Suction Tube Length		39"
Suction Tube Outlet OD Size		1.6"
Suction Tube Type		Centrifugal
Overall Length		48"
Metered		No
Special Features		Sanitary Pump
Application		Food Products
Agency Compliance		AtEx (Motor), 3A Certified (Pump)
Manufacturers Warranty Length		3 Years
Includes		Motor and Pump
