DAYTON Electric Chain Hoist, 0 to 16 fpm, 460V

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Electric Chain Hoist, Capacity 1000 lb., Lift 20 ft., Number of Speeds 2, Lift Speed 0 to 16 fpm, Motor HP 0.5, Voltage 460, 3 Phase, Min. Between Hooks 18-1/8 In., 1.7 Amps @ Low Volts, Classification H4, Housing Depth 18-11/16 In., Housing Length 23-1/8 In., Housing Width 18-11/16 In.Brake Multiple Disc Motor, Clutch Overload Limiting, Control Ergonomic NEMA 3R 24V Push Button Pendant w/Strain Relief, Control Cord 16 ft.

Grainger Item #	4ZY59
Price (ea.)	$3,990.00
Brand	DAYTON
Mfr. Model #	4ZY59
UNSPSC #	24101602
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	111.0
Availability	Item ships within 7 business days from supplier
Catalog Page No.	1409
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $529.00 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Item		Electric Chain Hoist
Capacity		1000 lb.
Lift		20 ft.
Number of Speeds		2
Lift Speed		0 to 16 fpm
Motor HP		0.5
Voltage		460
Phase		3
Min. Between Hooks		18-1/8"
Amps @ Low Volts		1.7
Classification		H4
Housing Depth		18-11/16"
Housing Length		23-1/8"
Housing Width		18-11/16"
Brake		Multiple Disc Motor
Clutch		Overload Limiting
Control		Ergonomic NEMA 3R 24V Push Button Pendant w/Strain Relief
Control Cord		16 ft.
Color		Red
Lubrication		Positive, Oil Bath Gear Case, Provides Cooler Operation and Longer Gear Life
Thermal Protection		No
Standards		ASME/ANSI B30.16, Metric Rated
Includes		Chain Container
