DAYTON Pump, Self Priming, Aluminum, 1/3 HP

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Centrifugal Pump, Chemical Transfer, Self Priming, 1/3 HP, Phase 1, Voltage 115/230, Amps 6.5/3.3, Housing Material Aluminum, Inlet 1-1/2 In, Outlet 1-1/2 In, Motor Enclosure ODP, 3450 RPM, Motor Type Capacitor-Start, Capacitor-Run, Max. Head 32 Ft., Suction Lift 25 Ft., Max. Fluid Viscosity 31 SSU, For General Purpose Chemical Transfer From Drums or Storage Tanks. Not Recommended for Perchloroethylene or Trichloroethylene, Includes Manual

Grainger Item #	6GPG4
Price (ea.)	$444.75
Brand	DAYTON
Mfr. Model #	6GPG4
UNSPSC #	40151503
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	28.83
Availability	Typically in Stock
Catalog Page No.	4079
Country of Origin (Country of Origin is subject to change.)	China

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $89.95 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Centrifugal Pump
Type		Chemical Transfer, Self Priming
HP		1/3
Phase		1
Voltage		115/230
Amps		6.5/3.3
Housing Material		Aluminum
Impeller Material		Aluminum
Wetted Materials		Aluminum, 304 Stainless Steel, Viton, Carbon, Ceramic
Hz		60
Inlet (In.)		1-1/2
Outlet (In.)		1-1/2
Motor Enclosure		ODP
NEMA/IEC Frame		56J
Motor RPM		3450
Motor Type		Capacitor-Start, Capacitor-Run
Shaft Material		Stainless Steel
Screw Material		Carbon Steel
Seal Type		Mechanical
Seal Material		304 Stainless Steel, Viton, Carbon, Ceramic
Seal Application		Non-Flammable Liquids Compatible with Pump Components
Max. Pressure (PSI)		13.9
GPM of Water @ 2 Ft. of Head		37
GPM of Water @ 5 Ft. of Head		35
GPM of Water @ 10 Ft. of Head		33
GPM of Water @ 15 Ft. of Head		21
GPM of Water @ 20 Ft. of Head		17
GPM of Water @ 25 Ft. of Head		12
GPM of Water @ 30 Ft. of Head		6
Max. Head (Ft.)		32
Suction Lift (Ft.)		25
Max. GPM @ Head (Ft.)		36 @ 2
Best Efficiency GPM @ Head (Ft.)		17 @ 20
Min. GPM @ Head (Ft.)		2 @ 31
Best Efficiency Range GPM @ Head (Ft.)		12-33 GPM @ 25-15 Ft.
Max. Liquid Temp. (F)		180
Max. Specific Gravity		1
Max. Case Pressure (PSI)		85
Max. Fluid Viscosity		31 SSU
Impeller Type		Semiclosed
Bearing Type		Ball
Duty		Continuous
Port Rotation		4 Position Increments
Drain Plug		Easily Accessible
Agency Compliance		CSA C & US
Manufacturers Warranty Length		1 Year
Application		For General Purpose Chemical Transfer From Drums or Storage Tanks. Not Recommended for Perchloroethylene or Trichloroethylene
For Use With		Nonflammable and Nonabrasive Liquids Compatible with Pump Wetted Materials
Height (In.)		10
Length (In.)		16-11/16
Width (In.)		7-5/16
Includes		Manual
