DAYTON Air Circulator, 16 In, 2450 cfm, 115V

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Air Circulator, Blade Dia. 16 In., Stationary, Non-Oscillating, Speeds 3, Voltage 115V, 1 Phase, CFM High 2450, CFM Low 1800Motor HP 1/6, Motor RPM 1300/1000/700, Operating Amps 1.5/1.0/0.75, Mounting Location Wall, Ceiling or Floor, Fan RPM 700/1000/1300, Light Commercial, Assembled Assembled, CFM Medium 2100Includes Wall and Ceiling Bracket

Grainger Item #	2LY91
Price (ea.)	$128.85
Brand	DAYTON
Mfr. Model #	2LY91
UNSPSC #	40101602
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	14.7
Availability	Typically in Stock
Catalog Page No.	4443
Country of Origin (Country of Origin is subject to change.)	China
California Proposition 65

See Compliance & Restrictions for important safety & regulatory information.
Qty.
Add Grainger TripleGuard® repair & replacement coverage for $35.95 each.
Price shown may not reflect your price. Sign in or register.

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Air Circulator
Blade Dia.		16"
Mobile/Stationary		Stationary
Oscillating/Non-Oscillating		Non-Oscillating
Speeds		3
Voltage		115V
Phase		1
CFM High		2450
CFM Low		1800
Motor HP		1/6
Motor RPM		1300/1000/700
Operating Amps		1.5/1.0/0.75
Mounting Location		Wall, Ceiling or Floor
Fan RPM		700/1000/1300
Environmental Applications		Light Commercial
Assembled		Assembled
CFM Medium		2100
Max. Ambient Temp.		105 Degrees F
Hz		60
Watts		120/90/65
Motor Type		Shaded Pole
Drive Type		Direct
Motor Enclosure		Open Air-Over
Motor Insulation		Class A
Thermal Protection		Auto
Bearing Type		Sleeve
Height		19"
Width		22"
Max. Depth		10"
Cord Length		9 ft.
Number of Blades		3
Blade Material		Black Painted Steel
Shaft Dia.		9.5mm
Housing Material		Steel
Guard Material		Steel
Wire Guard Finish		Chrome Plated
Application		People Cooling
Standards		UL/OSHA
Includes		Wall and Ceiling Bracket
