Surge Protection Device, Type 4, Location Type Type 3, Nominal Discharge Current 2kA, Voltage 120VAC/120VDC, Phase 1, Wire 6, Number of Poles 2, Max. Surge Current Per Phase 2kA, Max. Surge Current Per Mode 4kA, Max. Continuing Operating Voltage 150VAC/150VDCModes of Protection L-N/L/N-Gnd, Mounting Style DIN-RailEnclosure Type IP20Wire Gauge 12-18AWGLength 3.93, Width 0.71, Depth 2.56, Standards UL 1449 3rd Edition, IEC 61643-1, cUL, CSA, KEMA
  • Grainger Item #19D541
    Price (ea.)$228.25
    BrandCOOPER BUSSMANN
    Mfr. Model #BSPH2A150D150LVR
    UNSPSC #39121610
    Ship Qty. 1
    Sell Qty. (Will-Call) 1
    Ship Weight (lbs.)0.2
    Availability Typically in Stock
    Catalog Page No.302
    Country of Origin
    (Country of Origin is subject to change.)
    Germany
  • This item has been designated by the manufacturer as an environmentally preferable product (EPP) because this item is RoHS Compliant.
  • Price shown may not reflect your price. Sign in or register.
Check Availability Use your ZIP code to estimate availability.
  •
  •
  • Please wait...
ItemSurge Protection Device
TypeType 4
Location TypeType 3
Nominal Discharge Current2kA
Voltage120AC/120DC
Phase1
Wire6
Number of Poles2
Max. Surge Current Per Phase2kA
Max. Surge Current Per Mode4kA
Max. Continuing Operating Voltage150VAC/150VDC
Modes of ProtectionL-N/L/N-Gnd
Mounting StyleDIN-Rail
Enclosure TypeIP20
Wire Gauge12-18AWG
Length3.93
Width0.71
Depth2.56
StandardsUL 1449 3rd Edition, IEC 61643-1, cUL, CSA, KEMA
Green Certification or Other RecognitionRoHS Compliant


Optional Accessories

More Accessories

Brand:

COOPER BUSSMANN

Grainger Item #:

19D575

Price (ea.):

$120.55
