CHEMSTEEL Rotary Gear Pedestal Pump, GPM 10.5

Rotary Gear Pedestal Pump, High Temperature, Port Size 3/4 In., Recommended Motor HP 1 1/2, Motor Frame 56C, GPM @ Freeflow 10.5, .24 HP @ Free Flow, Suction Lift 9 Ft., Pump RPM 1725, Max. Temp. 450 F, Max. Pressure 150 PSI, Mechanical Seal, Manufacturers Warranty 12 Months From Date Of Shipment
  • Grainger Item #6KXR9
    Price (ea.)$2,556.00
    BrandCHEMSTEEL
    Mfr. Model #S41716CA
    UNSPSC #40151521
    Ship Qty. 1
    Sell Qty. (Will-Call) 1
    Ship Weight (lbs.)9.02
    Availability Typically in Stock
    Catalog Page No.4145
    Country of Origin
    (Country of Origin is subject to change.)
    USA
  • Price shown may not reflect your price. Sign in or register.
Check Availability Use your ZIP code to estimate availability.
  •
  •
  • Please wait...
ItemRotary Gear Pedestal Pump
TypeHigh Temperature
Pump Body Material316 Stainless Steel
Port Size (In.)3/4
Recommended Motor HP1 1/2
Motor Frame56C
GPM @ Freeflow10.5
HP @ Free Flow.24
GPM @ Freeflow @ 1725 RPM10.5
HP @ Free Flow @ 1725 RPM.24
GPM @ 20 PSI10.3
HP @ 20 PSI.42
GPM @ 25 PSI10.2
HP @ 25 PSI.47
GPM @ 40 PSI10.1
HP @ 40 PSI.60
GPM @ 50 PSI10.0
HP @ 50 PSI.69
GPM @ 60 PSI9.9
HP @ 60 PSI.78
GPM @ 75 PSI9.7
HP @ 75 PSI.92
GPM @ 80 PSI9.7
HP @ 80 PSI.97
GPM @ 100 PSI9.4
HP @ 100 PSI1.15
GPM @ 125 PSI9.2
HP @ 125 PSI1.37
GPM @ 125 PSI @ 1725 RPM9.2
HP @ 125 PSI @ 1725 RPM1.37
Suction Lift (Ft.)9
Suction Lift (Ft.) @ 1725 RPM9
Pump RPM1725
Max. Temp. (F)450
Temp. Range-50 Degrees to 450 Degrees
Max. Pressure (PSI)150
Max. Viscosity (SSU)500
Relief ValveNo
SealMechanical
Shaft Dia. (In.).625
Shaft Height (In.)3
Shaft Material316 Stainless Steel
Manufacturers Warranty Length12 Months From Date Of Shipment
