CENTURY Fan Motor, 1/3 HP, 1140 RPM, 56 Frame

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Transformer Cooling Fan Motor, 3-Phase, Totally Enclosed Air-Over Enclosure, HP 1/3, 1140 Nameplate RPM, Voltage 200-230/460, Full Load Amps 1.9-1.8/0.9, 60/50, Phase 3, 56 Frame, 1.50 Service Factor, Ambient Temperature 65 Degrees C, Insulation Class B, Duty Continuous Air-Over, Number of Speeds 1, Mounting Base/Stud, Double-Sealed Ball, Thermal Protection Auto, CW/CCW Rotation, Body Dia. 6-1/2 In., Length Less Shaft 10-5/16 In., 5/8 In. Shaft Dia., Shaft Length 1-7/8 In.

Grainger Item #	4UY24
Price (ea.)	$607.00
Brand	CENTURY
Mfr. Model #	H1040
UNSPSC #	26101612
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	28.45
Availability	Typically in Stock
Catalog Page No.	77
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $129.00 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Transformer Cooling Fan Motor
Motor Type		3-Phase
Enclosure		Totally Enclosed Air-Over
HP		1/3
Nameplate RPM		1140
Voltage		200-230/460
Full Load Amps		1.9-1.8/0.9
Hz		60/50
Phase		3
NEMA/IEC Frame		56
Frame		56
Service Factor		1.50
Ambient Temperature		65 Degrees C
Insulation Class		B
Duty		Continuous Air-Over
Number of Speeds		1
Mounting		Base/Stud
Bearings		Double-Sealed Ball
Thermal Protection		Auto
Rotation		CW/CCW
Body Dia.		6-1/2"
Length Less Shaft		10-5/16"
Shaft Dia.		5/8"
Shaft Length		1-7/8"
Bolt Circle Dia.		5-13/16"
Standards		UL Recognized (E46412), CSA Certified (LR43341)
Includes		190/380 V @ 50hz
