CENTURY Pool Pump Motor, 5 HP, 3450 RPM, 230VAC

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Pool Pump Motor, PSC, Open Dripproof, 5 HP, 3450 Nameplate RPM, 56Y NEMA/IEC Frame, CCW Rotation, Voltage 230, 16.4 Full Load Amps, 1 Phase, 60 Hz, Rigid Base Mounting, Ball Bearings, Black, Flange Material Aluminum, Shaft Threaded 3/8-16 UNC-2A RH, Shaft Material 303 Stainless Steel, Thermal Protection Auto, 1.00 Service Factor, Ambient Temperature 50 Degrees C, Shaft Dia. 1/2 In., Shaft Length 2-3/8 In., Insulation Class B, Efficiency Group Standard, Standards UL Recognized, CSA Certified

Grainger Item #	16U417
Price (ea.)	$629.00
Brand	CENTURY
Mfr. Model #	B238
UNSPSC #	26101602
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	39.95
Availability	Typically in Stock
Catalog Page No.	N/A
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $129.00 each.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Pool Pump Motor
Motor Type		PSC
Enclosure		Open Dripproof
HP		5
Nameplate RPM		3450
NEMA/IEC Frame		56Y
Frame		56Y
Rotation		CCW
Voltage		230
Full Load Amps		16.4
Phase		1
Hz		60
Mounting		Rigid Base
Bearings		Ball
Finish		Black
Flange Material		Aluminum
Shaft		Threaded 3/8-16 UNC-2A RH
Shaft Material		303 Stainless Steel
Thermal Protection		Auto
Service Factor		1.00
Ambient Temperature		50 Degrees C
Shaft Dia.		1/2"
Shaft Length		2-3/8"
Insulation Class		B
RPM Range		2350-3600
Efficiency Group		Standard
Standards		UL Recognized, CSA Certified
