CENTURY Condenser Fan Motor, 1/2 HP, 1075 rpm, 60Hz

Condenser Fan Motor, PSC, 1/2 HP, Nameplate RPM 1075, Voltage 460, 48Y Frame, Totally Enclosed Air-Over, Number of Speeds 1, Full Load Amps 3.0-3.0/1.5, Stud/Band/Hole Mounting, Auto Thermal Protection, Insulation Class F, Service Factor 1.0, Ball Bearings, Max. Ambient Temp. 70 Degrees C, CW/CCW Rotation, Overall Length 12-7/16 In., Shaft Dia. 1/2 In., Shaft Length 6 In., Capacitor Required 2MDV7
  • Grainger Item #1UMG2
    Price (ea.)$180.25
    BrandCENTURY
    Mfr. Model #FEH1056SF
    UNSPSC #26101604
    Ship Qty. 1
    Sell Qty. (Will-Call) 1
    Ship Weight (lbs.)18.94
    Availability Typically in Stock
    Catalog Page No.73
    Country of Origin
    (Country of Origin is subject to change.)
    Mexico
  • Price shown may not reflect your price. Sign in or register.
Check Availability Use your ZIP code to estimate availability.
  •
  •
  • Please wait...
ItemCondenser Fan Motor
Motor TypePSC
EnclosureTotally Enclosed Air-Over
HP1/2
Number of Speeds1
Nameplate RPM1075
NEMA/IEC Frame48Y
Frame48Y
Voltage460
Hz60
Phase1
Full Load Amps3.0-3.0/1.5
MountingStud/Band/Hole
Thermal ProtectionAuto
Insulation ClassF
Service Factor1.0
BearingsBall
Max. Ambient Temp.70 Degrees C
RotationCW/CCW
Overall Length12-7/16"
Length Less Shaft6-7/16"
Shaft Dia.1/2"
Shaft Length6"
Body Dia.5-5/8"
Stud Quantity4
Stud Pattern3-5/8 x 3-5/8"
Stud Size8-32"
Lead Length36"
Shaft TypeDouble Flat
Shaft OrientationUp/Down
FeaturesEnergy Efficient, Auto Protector, Extended Through Bolts
DutyContinuous Air-Over
Capacitor Required2MDV7
RPM Range1000-1380
StandardsUL Recognized (E25022), CSA Certified (LR 43341)
