CENTURY Condenser Fan Motor, 1-1/2HP, 850 rpm, 60Hz

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Condenser Fan Motor, 3-Phase, 1-1/2 HP, Nameplate RPM 850, Voltage 208-230/460, 56HZ Frame, Open Air-Over, Number of Speeds 1, Full Load Amps 7.2-6.7/3.6, Base/Stud/Band Mounting, Auto Thermal Protection, Insulation Class F, Service Factor 1.0, Ball Bearings, Max. Ambient Temp. 70 Degrees C, CW/CCW Rotation, Overall Length 25-1/16 In., Shaft Dia. 5/8 In., Shaft Length 6-1/16 In.

Grainger Item #	12J035
Price (ea.)	$625.00
Brand	CENTURY
Mfr. Model #	H1054A
UNSPSC #	26101612
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	47.24
Availability	Typically in Stock
Catalog Page No.	74
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $129.00 each.
Price shown may not reflect your price. Sign in or register.

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Condenser Fan Motor
Motor Type		3-Phase
Enclosure		Open Air-Over
HP		1-1/2
Number of Speeds		1
Nameplate RPM		850
NEMA/IEC Frame		56HZ
Frame		56HZ
Voltage		208-230/460
Hz		60
Phase		3
Full Load Amps		7.2-6.7/3.6
Mounting		Base/Stud/Band
Thermal Protection		Auto
Insulation Class		F
Service Factor		1.0
Bearings		Ball
Max. Ambient Temp.		70 Degrees C
Rotation		CW/CCW
Overall Length		25-1/16"
Length Less Shaft		19"
Shaft Dia.		5/8"
Shaft Length		6-1/16"
Body Dia.		6-1/2"
Bolt Circle Dia.		5-7/8"
Stud Quantity		4
Stud Pattern		4-1/8 x 4-1/8"
Stud Size		10-32"
Nominal Efficiency		71.5%
Shaft Type		Keyed with Single Flat
Shaft Orientation		Horizontal or Up
Features		Inverter Duty, Removable Rigid Base, Quick Disconnect Design
Duty		Continuous Air-Over
Application		HVAC
RPM Range		700-980
Standards		UL Recognized (E44549), CSA Certified (LR4642)
