CENTURY Mtr, 3 Ph, 1 HP, 1725, 200-230/460V, Eff 75.0

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Belt Drive Motor, 3-Phase, 1 HP, Nameplate RPM 1725, Voltage 200-230/460, 3 Phase, Frame 56, Open Dripproof, Full Load Amps 3.4-3.6/1.8, 60 Hz, Cradle Mounting, Thermal Protection None, Insulation Class B, Service Factor 1.25, Ball Bearings, Max. Ambient Temp. 40 Degrees C, Rotation CW/CCW, Overall Length 11-1/16 In., Shaft Dia. 5/8 In., Shaft Length 1-15/16 In.

Grainger Item #	6PWA6
Price (ea.)	$329.75
Brand	CENTURY
Mfr. Model #	H615V2
UNSPSC #	26101612
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	25.2
Availability	Typically in Stock
Catalog Page No.	83
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $75.95 each.
Price shown may not reflect your price. Sign in or register.

Mtr, 3 Ph, 1 HP, 1725, 200-230/460V, Eff 75.0

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Belt Drive Motor
Motor Type		3-Phase
HP		1
Nameplate RPM		1725
Voltage		200-230/460
Frame		56
Enclosure		Open Dripproof
Mounting		Cradle
Hz		60
Full Load Amps		3.4-3.6/1.8
Thermal Protection		None
Insulation Class		B
Service Factor		1.25
Bearings		Ball
Frame Material		Steel
Max. Ambient Temp.		40 Degrees C
Rotation		CW/CCW
Shaft Dia.		5/8"
Shaft Length		1-15/16"
Length Less Shaft		9-1/8"
Overall Length		11-1/16"
Body Dia.		6-1/2"
Stud Pattern		4-1/8 x 4-1/8"
Resilient Ring Dia.		2-1/2"
Ring to Ring Center		8-5/8"
Nominal Efficiency		75.0%
Duty		Continuous
RPM Range		1400-1800
Phase		3
Standards		UL Recognized (E44549), CSA Certified (LR4642)
Footnotes		26
