Belt Drive Motor, Split-Phase, 1/2 HP, Nameplate RPM 1725, Voltage 115/208-230, 1 Phase, Frame 48Z, Open, Full Load Amps 8.2/4.1, 60 Hz, Cradle Mounting, Thermal Protection Auto, Insulation Class B, Service Factor 1.25, Ball Bearings, Max. Ambient Temp. 40 Degrees C, Rotation CW/CCW, Overall Length 10-11/16 In., Shaft Dia. 1/2 In., Shaft Length 2-1/4 In., Includes 5/8 In. dia. Shaft Bushing

Grainger Item #	4UE99
Price (ea.)	$247.25
Brand	CENTURY
Mfr. Model #	BF2054V1
UNSPSC #	26101602
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	17.2
Availability	Typically in Stock
Catalog Page No.	82
Country of Origin (Country of Origin is subject to change.)	Mexico

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $55.95 each.
Price shown may not reflect your price. Sign in or register.

Motor, Sp Ph, 1/2 HP, 1725, 115/208-230V, 48Z

Enlarge Image

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		Belt Drive Motor
Motor Type		Split-Phase
HP		1/2
Nameplate RPM		1725
Voltage		115/208-230
Frame		48Z
Enclosure		Open
Mounting		Cradle
Hz		60
Full Load Amps		8.2/4.1
Thermal Protection		Auto
Insulation Class		B
Service Factor		1.25
Bearings		Ball
Max. Ambient Temp.		40 Degrees C
Rotation		CW/CCW
Shaft Dia.		1/2"
Shaft Length		2-1/4"
Length Less Shaft		8-7/16"
Overall Length		10-11/16"
Body Dia.		5-5/8"
Stud Pattern		3-5/8 x 3-5/8"
Resilient Ring Dia.		2-1/2"
Ring to Ring Center		7-15/16"
Nominal Efficiency		65.0%
Duty		Continuous
RPM Range		1400-1800
Phase		1
Standards		UL Recognized, CSA Certified
Footnotes		26, 307, 341
Includes		5/8" dia. Shaft Bushing
