CENTURY Motor, Cap St, 3/4 HP, 1725, 115/208-230V, 56

Belt Drive Motor, Capacitor-Start, 3/4 HP, Nameplate RPM 1725, Voltage 115/208-230, 1 Phase, Frame 56, Open Dripproof, Full Load Amps 11.0/5.4-5.5, 60 Hz, Cradle/Stud Mounting, Thermal Protection Auto, Insulation Class B, Service Factor 1.25, Ball Bearings, Max. Ambient Temp. 40 Degrees C, Rotation CW/CCW, Overall Length 11-1/16 In., Shaft Dia. 5/8 In., Shaft Length 1-7/8 In.
  • Grainger Item #4UB63
    Price (ea.)$305.75
    BrandCENTURY
    Mfr. Model #C426V1
    UNSPSC #26101602
    Ship Qty. 1
    Sell Qty. (Will-Call) 1
    Ship Weight (lbs.)27.1
    Availability Typically in Stock
    Catalog Page No.83
    Country of Origin
    (Country of Origin is subject to change.)
    Mexico
  • Price shown may not reflect your price. Sign in or register.
Check Availability Use your ZIP code to estimate availability.
  •
  •
  • Please wait...
ItemBelt Drive Motor
Motor TypeCapacitor-Start
HP3/4
Nameplate RPM1725
Voltage115/208-230
Frame56
EnclosureOpen Dripproof
MountingCradle/Stud
Hz60
Full Load Amps11.0/5.4-5.5
Thermal ProtectionAuto
Insulation ClassB
Service Factor1.25
BearingsBall
Max. Ambient Temp.40 Degrees C
RotationCW/CCW
Shaft Dia.5/8"
Shaft Length1-7/8"
Length Less Shaft9-3/16"
Overall Length11-1/16"
Body Dia.6-1/2"
Stud Pattern4-1/8 x 4-1/8"
Resilient Ring Dia.2-1/2"
Ring to Ring Center8-11/16"
Nominal Efficiency68.0%
DutyContinuous
RPM Range1400-1800
Phase1
StandardsUL Recognized, CSA Certified
Footnotes26
