CALDWELL Manual Release Hook, 15T

| Write a Review
| Read all Reviews
| Read all Ask & Answer

Manual Release Hook, Capacity 15 ton, Opening Height Above Lift Arm 3 In., Opening Width Above Lift Arm 2-1/2 In., Eye Hook Opening 2-17/64 In., Overall Height 49-1/4 In., Min. Load Basket/Choker 400 lb./200 lb., Max. Rigging Weight Basket/Choker 100 lb./50 lb., Body Dimensions 39-1/4 In.H x 15 In.W x 6-5/16 In.D, Bail Opening Height 9 In., Bail Opening Width 5 In., Bail Width 1-1/2 In., Material Above the Bail Opening 2-1/2 In., Lifting Arm Height 2-1/2 In.

Grainger Item #	5NVL3
Price (ea.)	$4,823.00
Brand	CALDWELL
Mfr. Model #	RR-15
UNSPSC #	24101616
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	375.0
Availability	Item ships within 4 business days from supplier
Catalog Page No.	1443
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Price shown may not reflect your price. Sign in or register.

Enlarge Image

Item		Manual Release Hook
Capacity		15 ton
Opening Height Above Lift Arm		3"
Opening Width Above Lift Arm		2-1/2"
Eye Hook Opening		2-17/64"
Overall Height		49-1/4"
Min. Lifting Sling Rope Dia.		1-1/2"
Min. Load Basket/Choker		400 lb./200 lb.
Max. Rigging Weight Basket/Choker		100 lb./50 lb.
Body Dimensions		39-1/4"H x 15"W x 6-5/16"D
Bail Opening Height		9"
Bail Opening Width		5"
Bail Width		1-1/2"
Material Above the Bail Opening		2-1/2"
Lifting Arm Height		2-1/2"
Required Lifting Sling Type		Wire Rope Eye and Eye Sling
Standards		ASME
