Power Transmission
>
Gearmotors
>
Gearmotors

BISON AC Gearmotor, Inverter, RPM 45, Torque 58

| Write a Review
| Read all Reviews
| Read all Ask & Answer

AC Gearmotor, Parallel Shaft, Voltage Rating 230, 3 Phase, - Hz, Single Shaft, Nameplate RPM 46, Full Load Torque (In.-Lbs.) 50.0, Overhung Load (Lb.) 120, Input HP 1/20, Gear Ratio 37:1, Full Load Amps 0.24, Insulation Class F, TENV Enclosure, No Thermal Protection, All Position Mounting, Motor Type 3-Phase, Unpainted Finish, 304 Stainless Steel Housing, Washdown, Includes -

Grainger Item #	5KNJ7
Price (ea.)	$1,272.00
Brand	BISON
Mfr. Model #	017-160-0037
UNSPSC #	20101617
Ship Qty.	1
Sell Qty. (Will-Call)	1
Ship Weight (lbs.)	12.13
Availability	Typically in Stock
Catalog Page No.	126
Country of Origin (Country of Origin is subject to change.)	USA

Qty.
Add Grainger TripleGuard® repair & replacement coverage for $199.00 each.
Price shown may not reflect your price. Sign in or register.

Check Availability Use your ZIP code to estimate availability.

Qty:
ZIP code:

Item		AC Gearmotor
Type		Parallel Shaft
Voltage Rating		230
Phase		3
Shaft Orientation		Parallel
Reversible Shaft Output		Yes
Shaft		Single
Nameplate RPM		46
RPM @ 50 Hz		30
No Load RPM		48
Full Load Torque (In.-Lbs.)		50.0
Starting Torque (In.-Lb.)		102
Overhung Load (Lb.)		120
Input HP		1/20
Gear Ratio		37:1
Full Load Amps		0.24
Full Load Amps @ 230V		0.2343
Insulation Class		F
Enclosure		TENV
Thermal Protection		No
Ambient (C)		40
Rotation		Reversible
Mounting		All Position
Motor Type		3-Phase
Length Less Shaft (In.)		230.5mm
Shaft Dimensions (In.)		16mm X 40mm
Keyway (In.)		5mmSQ X 25mm
Bearings		Sealed Ball
Lubrication		Food-Grade Grease
Lubrication Quantity (Qt.)		0.14
Finish		Unpainted
Housing		304 Stainless Steel
Gear Case		304 Stainless Steel
Gears		Steel
Seals		Triple Lip Cartridge Seal With Stainless Slinger
Application		Washdown
Agency Compliance		UL Listed
RPM Range		31 to 50
